Part No

Emitting

Color

Chip

Material

Lens Color

Forward

Voltage

Luminous

Intensity

(Typ)

Dominant

Wavelength

（Chromatic Coordinates）

Reverse

Current

50% Power Angle

Luminous

 Flux(Typ)

IF=20mA

IF=20mA

IF=20mA

VR=5V

IF=20mA

IF=20mA

3004SOL

Red

AlGaInP

Water Clear

1.7-2.4V

1000mcd

620-630nm

<5uA

15°

0.8lm

3004TOL

Red

AlGaInP

Water Clear

1.7-2.4V

2500mcd

620-630nm

<5uA

15°

2.2lm

3004SYS

Yellow

AlGaInP

Water Clear

1.7-2.4V

1000mcd

580-595nm

<5uA

15°

0.8lm

3004TSY

Yellow

AlGaInP

Water Clear

1.7-2.4V

2500mcd

580-595nm

<5uA

15°

2.2lm

3004UPG

Green

InGaN

Water Clear

2.8-3.6V

4500mcd

515-530nm

<5uA

15°

3.5lm

3004UB

Blue

InGaN

Water Clear

2.8-3.6V

2000mcd

465-475nm

<5uA

15°

0.8lm

3004UW-A

White

InGaN

Water Clear

2.8-3.6V

6000mcd

X:0.29 Y:0.30

<5uA

15°

4.5lm

3004UW-B

White

InGaN

Water Clear

2.8-3.6V

8000mcd

X:0.29 Y:0.30

<5uA

15°

6.0lm

3004UWY-A

Warm

White

InGaN

Water Clear

2.8-3.6V

6000mcd

X:0.45 Y:0.41

<5uA

15°

4.5lm

3004UWY-B

Warm

White

InGaN

Water Clear

2.8-3.6V

8000mcd

X:0.45 Y:0.41

<5uA

15°

6.0lm
