Part No

Emitting

Color

Chip

Material

Lens Color

Forward

Voltage

Luminous

Intensity

(Typ)

Dominant

Wavelength

（Chromatic Coordinates）

Reverse

Current

50% Power Angle

Luminous

 Flux(Typ)

IF=20mA

IF=20mA

IF=20mA

VR=5V

IF=20mA

IF=20mA

5084SOL

Red

AlGaInP

Water Clear

1.7-2.4V

250mcd

620-630nm

<5uA

60°

0.8lm

Red

AlGaInP

Water Clear

1.7-2.4V

100mcd

620-630nm

<5uA

150°

0.8lm

5084TOL

Red

AlGaInP

Water Clear

1.7-2.4V

800mcd

620-630nm

<5uA

60°

2.2lm

Red

AlGaInP

Water Clear

1.7-2.4V

450mcd

620-630nm

<5uA

150°

2.2lm

5084SYS

Yellow

AlGaInP

Water Clear

1.7-2.4V

250mcd

580-595nm

<5uA

60°

0.8lm

Yellow

AlGaInP

Water Clear

1.7-2.4V

100mcd

580-595nm

<5uA

150°

0.8lm

5084TSY

Yellow

AlGaInP

Water Clear

1.7-2.4V

800mcd

580-595nm

<5uA

60°

2.2lm

Yellow

AlGaInP

Water Clear

1.7-2.4V

450mcd

580-595nm

<5uA

150°

2.2lm

5084UPG

Green

InGaN

Water Clear

2.8-3.6V

2000mcd

515-530nm

<5uA

60°

3.5lm

Green

InGaN

Water Clear

2.8-3.6V

500mcd

515-530nm

<5uA

150°

3.5lm

5084UB

Blue

InGaN

Water Clear

2.8-3.6V

600mcd

465-475nm

<5uA

60°

0.8lm

Blue

InGaN

Water Clear

2.8-3.6V

150mcd

465-475nm

<5uA

150°

0.8lm

5084UW-A

White

InGaN

Water Clear

2.8-3.6V

1800mcd

X:0.29 Y:0.30

<5uA

110°

5.0lm

5084UW-B

White

InGaN

Water Clear

2.8-3.6V

2500mcd

X:0.32 Y:0.35

（日光灯用）

<5uA

110°

7.0lm

5084UWY-A

Warm

White

InGaN

Water Clear

2.8-3.6V

1800mcd

X:0.45 Y:0.41

<5uA

110°

5.0lm

5084UWY-B

Warm

White

InGaN

Water Clear

2.8-3.6V

2500mcd

X:0.45 Y:0.41

<5uA

110°

7.0lm
