Part No

Emitting

Color

Chip

Material

Lens Color

Forward

Voltage

Luminous

Intensity

(Typ)

Dominant

Wavelength

（Chromatic Coordinates）

Reverse

Current

50% Power Angle

Luminous

 Flux(Typ)

IF=20mA

IF=20mA

IF=20mA

VR=5V

IF=20mA

IF=20mA

1044TOL-A

Red

AlGaInP

Water Clear

1.7-2.4V

250mcd

620-630nm

<5uA

120°

1.2lm

1044TOL-B

Red

AlGaInP

Water Clear

1.7-2.4V

400mcd

620-630nm

<5uA

120°

2.0lm

1044TSY-A

Yellow

AlGaInP

Water Clear

1.7-2.4V

250mcd

580-595nm

<5uA

120°

1.2lm

1044TSY-B

Yellow

AlGaInP

Water Clear

1.7-2.4V

400mcd

580-595nm

<5uA

120°

2.0lm

1044UPG-A

Green

InGaN

Water Clear

2.8-3.6V

700mcd

515-530nm

<5uA

120°

2.5lm

1044UPG-B

Green

InGaN

Water Clear

2.8-3.6V

1000mcd

515-530nm

<5uA

120°

3.5lm

1044UB

Blue

InGaN

Water Clear

2.8-3.6V

250mcd

465-475nm

<5uA

120°

0.7lm

1044UW-A

White

InGaN

Water Clear

2.8-3.6V

700mcd

X:0.29 Y:0.30

<5uA

120°

4.5lm

1044UW-B

White

InGaN

Water Clear

2.8-3.6V

1000mcd

X:0.29 Y:0.30

<5uA

120°

6.0lm

1044UW-C

White

InGaN/SiC

Water Clear

2.8-3.6V

800mcd

X:0.29 Y:0.30

<5uA

120°

5.5lm

1044UWY-A

Warm

White

InGaN

Water Clear

2.8-3.6V

700mcd

X:0.45 Y:0.41

<5uA

120°

4.5lm

1044UWY-B

Warm

White

InGaN

Water Clear

2.8-3.6V

1000mcd

X:0.45 Y:0.41

<5uA

120°

6.0lm

1044UWY-C

Warm

White

InGaN/SiC

Water Clear

2.8-3.6V

800mcd

X:0.45 Y:0.41

<5uA

120°

5.5lm
